Building Eurorack Modules

I have been doing a lot of soldering recently, getting right into it. Started doing some very small SMT for the first time too. So far I have built over 25 modules.

I have been streaming some of my builds on my youtube channel, https://www.youtube.com/user/vespine/videos but haven't really figured out a good reason why yet, mainly just for tracking progress I suppose. Planning to stream some noise making sessions eventually when I work out how to get the audio mixed in well without having to do a lot of post production, not sure if that's too much to ask.

Next level soldering

Overdue for an update, but too busy soldering :)

Do Androids Dream of Eurorack?

I have been dreaming of eurorack for a long time, I've decided to pull the pin and make it my next project.

To begin with i'm going entirely DIY. I have a rough plan and i'm building my own case. I'll be occasionally documenting progress and ideas.

I have a doepfer A-100 DIY power supply to start with and the first kit I've built is a befaco even VCO.

This is the current plan https://www.modulargrid.net/e/racks/view/734410

Some of these modules will test my soldering skills, there's a few quite small SMT builds involved. I bought a little "practice" kit on eBay to make sure i'm up to it.

Major LED Cube update

When I created my 8x8x8 LED cube about 8 years ago, I programmed some fairly basic "patterns" into it. I'm only a novice programmer and I was happy with the result but I always imagined I would go back at some point and spend some more time programming some really great patterns.

Then I had some kids and they actually love the cube, and more and more I've been itching to get back and spruce it up with some fancy patterns.

Then around my birthday a couple of months ago I learned a new Raspberry Pi was released and it occurred to me that this would be an awesome platform for a "cube pattern generator" and so I started doing some research and hacking. I investigated replacing the PIC32 all together with an RPi and it's maybe possible but I decided that it was best to leave the PIC32 driving the TLC led drivers, even if the Rpi could do it "as good", there's no way it was going to do it "better". So the alternative is to leave the PIC32 as the drawing device and just feed the "patterns" to it from the RPi.

Before tackling the task of interfacing the two devices, which I knew wasn't going to be a picnic; I decided to test out some things and blow some rust off the old programming skills by building an LED Cube simulator. So I got a raspberry pi pattern generator talking to a LED cube simulator on my PC, to test out that everything worked how I expected, and I thought it would be cool to make one since I did just look for something open source first but couldn't find anything. Now anyone can use the LED cube simulator to make patterns or just "learn" without having to have built a LED cube first. I am hosting it and the pattern generator on github https://github.com/vespine/LED_Cube_Simulator

Fast forward about 4 weeks and I now have the RPi feeding patterns to my actual LED cube and the led cube simulator at the same time! and it's awesome, to see the hardware and software, both of which I created, running in unison is quite cool.

So, I haven't actually got to the part where I create the cool patterns, that will be the next bit after I take a little bit of a break from staring at configuration registers and bit translations!

Here's some media. I will put up some posts detailing some of the technical aspects in the future.

Steam punk clock - LONG overdue

I bought a nixie tube clock kit back in 2011 and for the most part since then it has been sitting collecting dust. I would come back to it every few months and spend some time thinking about it and trying a few different things, but it was one of those projects I just could not work out how to get quite right!

Well I finally decide to get it done and here is the result. Click the picture for a nicer view.

It's not quite how I imagined it originally, but I am extremely pleased with the results. It could do with some sides, but I could not find matching wood, so that's something i'll keep my eye out for in the future. I'll take some detail photos later for another post.

If you are interested I bought the clock kit from http://www.pvelectronics.co.uk/ very happy to see the site is still in the business.

DIY Pantry light upgrade, fit for a king.

My pantry is in the corner of the kitchen and doesn't get a lot of light. I got tired of rummaging around the back shelves trying to read spice labels and ingredients of various packets. Adding some additional lighting has been on my mind for a while but I've never come across a solution which I completely liked, that is until I found LED strips on eBay. Cheap and easy and amazing!

Before

Add LED strip

Some basic mounting and soldering

A micro switch to turn it off when the door closes

After!

The LED strip was only $6 including shipping! I bought 5 meters and I've only used 1.8m. There is a "big brother" LED strip called the 5050, but honestly, it's almost too bright as it is. There are also fancy RGB led strips which are cool but I really only needed white light in my pantry.  I also bought a $9 power supply, 12v 5A, because I "thought" I might run the light up both sides and maybe on the top too, but it turns out that running up one side is more then enough, so here's the kicker: the whole thing burns about 7 watts! This means I can replace my 5A power supply with a 1A one for $5!

Fortunately, to the immediate right of the pantry is a space where the microwave sits and it already had a double power socket, with the microwave using only 1. This meant all I had to do was drill a hole between the 2 cavities and plug the power point in behind the microwave.

The last thing of expense was the tri quad, (the little triangle piece of wood you can see the strip is stuck to) I could have stuck the strip straight onto the inside of the pantry, but I thought it would be better if the light angled a bit into the pantry. Also when you stick your head in there, if the lights were just flush against the wall they would glare right into your eyes. So I bought a length of 8mm tri quad for about $6. So all up the project cost me $20 (I had the switch and wires already, that would have been an extra dollar or two.)

Overall, this project was a 10! If I do say so myself. Whipped it up in one afternoon and an absolutely amazing result. And I still have over 3m of LED strip left!  Now I just have to be careful I don't cover my whole house in LED strips:)
